3/4 Inch Stainless Steel 316 Air-Operated Double Diaphragm Pump

Wetted Body Material: Stainless Steel 316

Center Air Chamber Material: Aluminum Alloy

Diaphragm material: Teflon (TFM), Polyethylene(UPE), Santoprene (STP)

It is suitable for the transportation of glycol, alcohol, sodium hydroxide, nitric acid, carbonic acid, fruit acid, enzyme, caustic soda, ammonia, asphalt, and some acid & alkali liquid, but not suitable for hydrochloric acid, dilute sulfuric acid...

Elevate and optimize your fluid transfer processes with DYI SHENG's exceptional high-quality double diaphragm pump. Featuring a dual diaphragm design, it stands as the epitome of balanced and consistent fluid transfer, effectively minimizing downtime and reducing the need for frequent maintenance. What sets it apart is not just its reliability but also its ease of use, thanks to its compact and lightweight design, which ensures straightforward installation and remarkable mobility.

Diaphragm Specification:

Material	Temperature Range
UPE (U)	+5 to +50°C
TFM (T)	-30 to +130°C
Stantoprene ® (O)	0 to + 80°C

Specification:

Suction/ Discharge Port Size	3/4” PT(BSP)
Air Inlet Port Size	1/4” PT(BSP)
Air Exhaust Port Size	3/8” PT(BSP)
Min Air Inlet Pressure	0.5 Bar(kgf/cm²) ; 7.25psi
Max Air Inlet Pressure	8 Bar(kgf/cm²) ; 116psi
Best Air Inlet Pressure Range	1.5~3.5 Bar(kgf/cm²) ; 21.75psi~50.76psi
Discharge Volume Per Cycle	310 ml/cycle
Max Solids Handling	⌀2.4mm
Max Air Consumption	750Liter/Per Min.;26.49 SCFM
Max Wet Suction Lift	6.7 m
Packing Dimensions	26Lx24Wx35H(cm), 0.77Cuft
Net Weight	11.5 KG
Max flow rate	22.45 Gallon/Per Min. ; 85 Liter/Per Min.
Liquids Serviceability	Suitable almost all alkaline liquids and most acidic liquids, such as ethylene glycol, ethanol, sodium hydroxide, nitric acid, carbonic acid, fruit acids, enzymes, caustic soda, ammonia and asphalt. It also suitable wines and food sauces. Transport of some edible raw materials such as syrup, etc., but must be cleaned regularly. But it is not suitable for some special liquids such as dilute sulfuric acid, hydrochloric acid, hydrogen bromide, aqua regia, and chlorine. It can be used in the pharmaceutical industry, food industry, chemical industry, etc.

➤Product Advantage

Effortless mobility and straightforward installation are inherent features of this pneumatic diaphragm pump.
Low maintenance cost.
Can run dry for extended periods without damage.
Ensures 100% no-stall work efficiency.
Comes with a one-year warranty period, with a maximum of three years warranty for the diaphragm.
Suitable for conveying corrosive and abrasive substances.
Capable of handling high viscosity fluids.
Does not affect the integrity of the conveyed material.
Safe to use in flammable and explosive environments.
Pipe blockage does not lead to excessive load, overheating, or explosions.
Provides high accuracy in its operation.

➤Product Certifications

DYI SHENG is a professional manufacturer of air-operated double diaphragm pump in Taiwan. Dedicated to product research and development, we now have CE, ATEX, and ISO9001 quality certifications. We take high-quality, swift service, innovative technology, honesty, and trustworthiness as our guiding principles.
